Sirio SY 910 GSM/LoRa Base Antenna

SIR-060-999
Sirio SY 910 GSM/LoRa Base Antenna

Key features of Sirio SY 910 GSM/LoRa Base Antenna

• Type: 6 elements Yagi
• Frequency range: 698-960 MHz
• Systems: GSM-R, GSM-900, ISM/SIGFOX/LoRa 868MHz
• Impedance: 50Ω
• Radiation (H-plane): beamwidth @ -3 dB = 44°
• Radiation (E-plane): beamwidth @ -3 dB = 38°
• Polarization: linear vertical
• Gain: 15 dBi
• Front to back ratio: ≥ 12-15 dB (depending on frequency)
• Max. Power (CW) @ 30°C: 10 Watts
• Connector: FME male

Gross price (including 27% VAT): 51.74€ (Net price: 40.74€)
Special gross price: 47.80€ (Net price: 37.64€)
7,61% discount
Add to Cart Price Watch
You can ask for e-mail price notifications when the price of this product gets under a limit you specify. To use this feature you need to have a user account and to be signed in.

Further details of Sirio SY 910 GSM/LoRa Base Antenna

• Materials: Aluminium, steel, thermoplastic, nickel plated brass
• Wind resistance: 180 Km/h
• Wind load: 27 N at 150 Km/h
• Wind surface: 0,02 m²
• Dimensions: 210 x 595 x 60 mm
• Weight (approx.): 410 gr
• Mounting mast: Ø 25-42 mm
