Icom IP100FS Dispatcher Software
• Dispatcher software for IP100H radio and IP1000C controller
• Localization of IP100H radios with the use of access points
• Shows the status of IP100H radios
• Personalised call buttons
• Shows the received and sent text messages
• Works on Windows operation system
• Supplied USB hardware key
General description of Icom IP radio system
Icom's new innovative IP advanced radio system provides the ability to contact any member of your staff at any time utilising an existing or new IP/WLAN network. The WLAN based system offers a scalable license-free communication system using standard wireless networking products infrastructure, infrastructures that in many cases, may already be in place.
To discover the benefits of Icom’s new Revolutionary IP Advanced Radio System, click Download Icom’s IP Advanced Radio System PDF Guide.
The system is particularly suitable for:
- Hotels and resorts
- Shopping centres and department stores
- Restaurants / catering
- Tunnels and underground buildings
- Historic Buildings and museums
- Private communications onboard vessels
Licence Free system...no call charges
Radio licences are not required for this system, when using standard wireless networking infrastructure. The system uses the IEEE 802.11 a/ b/ g/n.
Scalable, yet Secure System
The IP/WLAN system from Icom offers a scalable licence-free communication system using standard wireless networking products infrastructure, which in most cases may already be in place. Secure encrypted communication is provided by the WPA-PSK and WPA-PSK2 wireless security protocols that encrypts calls.
Multiple Simultaneous Use (Full Duplex)
12 full duplex calls can transmit simultaneously at any one time. With an optional headset, the IP100H transceiver can talk and receive at the same time like a phone call.
Information terminal position
The optional IP100FS software receives information about the location of each transceiver based on the access point to which it is recorded and represent it graphically on the screen.
Simple system to manage
The IP1000C programs almost all transceiver configurations over the air. Individual PC programming via cable connection is not required.
2 Systems currently available
There are currently two versions of this IP Advanced radio system. Up to 20 users and up to 100 users.
Different types of calls
The IP100H/IP100FS can make individual call, group conference call, all call and area call. The unique area call function allows you to call any user who is accessing the specified access point.
The mixing function receives multiple users voices at the same time. Multiple communication is possible and increases efficiency of information sharing.
In a network consisting of two or more access points connected via IP, a transceiver can roam from an access point to another without losing communication.
Short text messages and status
The IP100H/IP100FS can send status and short data messages* to other users. The IP100H vibrates powerfully when receiving these messages. * Preprogrammed message only for IP100H.
Functions Remote Monitor, Kill, Stun and Revive *
In an emergency, the IP100FS can force an individual IP100H to transmit anything the microphone hears to identify the situation. If the IP100H is used by an unauthorized person, a remote kill command can be sent to disable the unit. * These commands can be transmitted from IP100FS.
IPX7 waterproof (only IP100H)
The IP100H can resist immersed in water up to a depth of 1 metre for 30 minutes.
IP Phone and Transceiver Interconnection
With the VE-PG3 RoIP gateway, the IP advanced radio system can interconnect with an IP phone, analogue transceiver and IDAS™ NXDN™ digital transceiver.
Lithium -Ion Battery BP-271, antenna, belt clip and user manual.
Can be added to the system:
- Optional software IP100FS, which acts as a radio dispatcher.
- The access point Icom AP-90M. The system also works with third-party access point *(IEEE 802.11 a / b / g / n)
* Icom does not guarantee compatibility with all brands on the market
- Management software access point RS-AP3
