Triax TOMT-1550 CATV/IF Optical Mini Transmitter

Further details of Triax TOMT-1550 CATV/IF Optical Mini Transmitter

The Triax TOMT-1550 is an Optical Mini Transmitter operating at a wavelength of 1550 nm with 3 dBm optical output power. It is designed for FTTH (Fibre To The Home) networks and has an operating frequency range of 47-2400 MHz.

Triax TOMT-1310 Optical Mini Transmitter main features

• Product number: 307918
• Type: TOMT-1550
• Product type: Optical Mini Transmitter
• Optical wavelength: 1550 nm
• Optical output power: 5 dBm
• CATV/IF frequency range: 47-2400 MHz
• Designed for FTTH (Fibre To The Home) networks
• Excellent linearity and flatness
• High return loss
• Uses GaAs amplifiers
• Ultra low noise technology
• Uses DFB coaxial small package laser
• Compact design for easier installation
• Red LED for power indication

The TOMT-1550 provides a 13/18 V, 0/22 kHz output for LNB use.

TOMT-1550 Point to Point use and power supply

• For Point to Point use with Triax TOMR Mini Receiver
• Each installed TOMT requires a 2 A, 18 V PSU
• UK PSU article number: 318166UK
• EU PSU article number: 318163EU
• PSU sold separately
