Triax GHV 930 Low Noise Coaxial House Distribution Amplifier

TRI-016-999
Triax GHV 930 Low Noise Coaxial House Distribution Amplifier
Triax GHV 930 Low Noise Coaxial House Distribution AmplifierTriax GHV 930 Low Noise Coaxial House Distribution AmplifierTriax GHV 930 Low Noise Coaxial House Distribution Amplifier

Key features of Triax GHV 930 Low Noise Coaxial House Distribution Amplifier

• The TRIAX GHV 930 professional broadband amplifier is suitable for amplifying signals from terrestrial antennas, antenna systems and cable networks
• Frequency range: 47-1006/85-1006 MHz
• Equalisation: 0-15
• Quieting: 0-15 dB
• Gain: 30 (1006 MHz) dB
• Gain return (60 MHz): 22/28 dB
• Noise figure: 7 dB
• RF connector - test point input: bidirectional -20 dB
• RF connector - test point output: directional -20 dB
• Dimensions: 65 mm (height) x 170 mm (width) x 100 mm (depth) x 0.714 kg
• IP20 protection

The product is ordered directly from the Hungarian importer. The lead time is approximately 2-3 business days if the product is in stock, otherwise it is subject to confirmation by the importer.
Gross price (including 27% VAT): 95.90€ (Net price: 75.51€)
Add to Cart Price Watch
You can ask for e-mail price notifications when the price of this product gets under a limit you specify. To use this feature you need to have a user account and to be signed in.
2 year(s) warranty Based on product sizes and weight, considering the minimal order quantity, this product is eligible for delivery to GLS parcel machines in Hungary.
Triax_GHV_930_catalog_en.pdf
English prospectus

Triax_GHV_930_manual_en.pdf
English user guide

2 year(s) warranty Based on product sizes and weight, considering the minimal order quantity, this product is eligible for delivery to GLS parcel machines in Hungary.

Further details of Triax GHV 930 Low Noise Coaxial House Distribution Amplifier

Triax GHV 900 series is a low noise coaxial house- and apartment- distribution amplifier, for use in smaller CATV distribution networks in multi dwelling houses.


• Output level CSO @ 60 dB IMD - 101 dBµV
• Output level CSO @ 60 dB IMD (42 cs) Slope 0/7 dB - 103/105 dBµV
• Output level CTB @ 60 dB IMD - 101 dBµV
• Output level CTB @ 60 dB IMD (42 cs) Slope0/7 dB - 103/105 dBµV
