Mean Well NPB-240-24TB 24V 8A Programmable Battery Charger

ENG-002-999
Mean Well NPB-240-24TB 24V 8A Programmable Battery Charger

Key features of Mean Well NPB-240-24TB 24V 8A Programmable Battery Charger

• Output voltage range: 21-42 V DC
• Rated charging current: 8 A
• Rated power: 240 W
• Programmable 2 or 3 stage charging characteristic
• For lead-acid and lithium-ion batteries
• Built-in CANBus communication
• Operating temperature: -30 to +70 C
• TB version with screw terminal connection

The product is ordered directly from the Hungarian importer. The lead time is approximately 2-3 business days if the product is in stock, otherwise it is subject to confirmation by the importer.
Gross price (including 27% VAT): 70.96€ (Net price: 55.88€)
Add to Cart Price Watch
You can ask for e-mail price notifications when the price of this product gets under a limit you specify. To use this feature you need to have a user account and to be signed in.
2 year(s) warranty
Mean_Well_NPB_240_24TB_akkumulatortolto_en.pdf
English prospectus

2 year(s) warranty

Further details of Mean Well NPB-240-24TB 24V 8A Programmable Battery Charger

The Mean Well NPB-240-24TB is a programmable battery charger with a rated power of 240 W and a rated charging current of 8 A. Its output voltage range is 21-42 V DC. It can be used with lead-acid and lithium-ion batteries and supports 2 or 3 stage charging characteristics.

Mean Well NPB-240-24TB charging characteristics

• Rated power: 240 W
• Rated charging current: 8 A
• Output voltage range: 21-42 V DC
• 2 or 3 stage charging characteristic
• Programmable charging parameters
• Lead-acid battery support
• Lithium-ion battery support


The charging characteristic of the NPB-240 series is programmable. The charger can operate with a 2 or 3 stage charging curve, allowing the charging parameters to be configured according to the requirements of the battery.

Mean Well NPB-240-24TB communication and control

• Built-in CANBus communication
• Programmable charging voltage
• Programmable charging current
• Programmable charging time
• Programmable charging characteristic


The built-in CANBus interface provides communication and programming capability. Charging voltage, charging current, charging time and charging characteristics can be configured.

NPB-240-24TB battery charger protection functions

• Short circuit protection
• Overvoltage protection
• Overtemperature protection
• Battery reverse polarity protection


The built-in protection functions include protection against short circuit, overvoltage, overtemperature and reverse battery polarity.

Mean Well NPB-240-24TB environmental specifications

• Operating temperature: -30 to +70 C
• Storage temperature: -40 to +85 C
• Operating relative humidity: 20-95%, non-condensing
• Storage relative humidity: 10-95%, non-condensing

Mean Well NPB-240-24TB mechanical design

• Screw terminal connection
• Dimensions: 150 x 90 x 43 mm
• Weight: 0.85 kg

NPB-240-24TB additional features

• Active PFC function
• Fanless design
• Cooling by free air convection
• LED status indication
