Icom IC-7110 HF/VHF/UHF All Mode Transceiver

Further details of Icom IC-7110 HF/VHF/UHF All Mode Transceiver

The Icom IC-7110 HF/VHF/UHF all mode transceiver supports HF, 50 MHz, 70 MHz, 144 MHz, 430 MHz and 440 MHz bands. The 70 MHz band is available only on the European version. Supported operating modes are SSB, CW, RTTY, AM, FM and D-STAR DV. The transceiver delivers 100 W output on HF/50 MHz and 50 W on VHF/UHF. FM broadcast and airband reception are also supported.

Icom IC-7110 Dualwatch and multi-band operation

• The receiver section incorporates independent circuits for HF/50 MHz and VHF/UHF
• True Dualwatch operation
• Operating modes can be set independently for each band
• VHF or UHF operation is possible while monitoring HF band conditions

The IC-7110 Dualwatch function can be used for HF/VHF and HF/UHF operation.

IC-7110 Real-Time Spectrum Scope and Waterfall Display

• Real-time spectrum scope
• Waterfall display
• The real-time scope allows quick identification of open frequencies
• Displays band conditions
• Provides rapid access to target signals
• The waterfall display provides a graphical view of how received signals change over time

The 4.3-inch large color display supports touch operation.

Icom IC-7110 CW Decoder

• Built-in CW Decoder
• The CW Decoder uses the solution from the IC-7300MK2
• Decode key speed settings: AUTO, LOCK, KEY SPEED link
• Decode filter settings: AUTO, FIX
• Threshold settings: AUTO, MANUAL

Decoding accuracy may vary depending on reception conditions.

IC-7110 Simple Configuration for FT8 Operation

• Simplified FT8 preset
• Selecting FT8 from the Preset menu automatically configures all required parameters
• Normal operation can be restored by selecting Normal
• Presets 3-5 can store new preset information
• The presets allow future digital modes, such as SSTV, to be supported

The parameters required for FT8 operation can be configured from the Preset menu.

Icom IC-7110 Wi-Fi and Bluetooth connectivity

• Wi-Fi 2.4 GHz and 5 GHz
• Bluetooth connectivity
• Wi-Fi provides Internet access for Terminal and Access Point modes
• Wireless connection to a smartphone or PC
• Bluetooth headset pairing
• Hands-free operation with a Bluetooth headset
• Online updates for D-STAR repeater lists via Wi-Fi
• Online firmware updates via Wi-Fi

Wireless connections also support the use of smartphone or PC applications.

IC-7110 D-STAR functions

• D-STAR DR mode
• Terminal/Access Point mode
• DV repeater monitor
• Picture transmission
• Picture reception and viewing directly on the IC-7110
• No external device is required for picture reception and viewing

The IC-7110 offers a full suite of D-STAR functions, including DR mode, Terminal/Access Point mode and DV repeater monitor.

Icom IC-7110 Controller connectors and mounting points

• USB Type-C port
• microSD card slot
• AMPS hole pattern
• Magnet for optional accessories
• 1/4-20 tripod mount
• Microphone connector
• Main Unit Connection Port
• Electronic Keyer Jack
• Headphone Jack

The Controller includes a dedicated USB Type-C port, microSD card slot, microphone connector, electronic keyer jack and headphone jack.

IC-7110 Main Unit connectors

• HF/50 MHz antenna connector
• 144/430 MHz antenna connector
• GND Terminal
• Microphone Connector
• External Speaker Jack
• Remote Jack
• DATA1 Jack
• USB Type-C Port
• ACC Socket
• DATA2 Socket
• Controller Connector
• Tuner Connector
• DC Power Input Connector
